IH Midsize H Closed Grill High Post Pedal Tractor

IH MIDSIZE “H” CLOSED GRILL HIGH POST
Manufactured by Eska in the early 1950’s.
Has bronze bushings in the body of the tractor.

DECALS, GRILL, TIRES: Same as Low Post
RIMS: STAR RIMS with low dome hubcaps
HUBS: Most have Curved top hub, but can have hub with “V” shaped groove on top
Both Hubs held on with two rivets.
CHAIN: Skip Tooth
REAR AXLE: 7/16”
PEDALS: Tear drop, solid rubber with metal ends held on with domed pushnuts
STEERING WHEEL: Flat bar
SEAT BRACKET: 1/2” from rear of tractor
SEAT: Should have metal spring support. Can have 2 kinds of seats. One is a thinner H pattern stamped steel seat & the other is the pan type found on the other Mid Size “H’s”
HITCH: Just a hole in the casting

Check out the video with more information closeups.

http://youtu.be/g0YEn-8ByMs
